Washer-Fixture Cleaning Machine ,CW-5200 Specifications:

• Cleaning basket size ：1000mm Diameter round basket × 200mm(H) , Special size need to be customized

• Cleaning fluid capacity ：80L（ maximum ）

• Rinse fluid capacity ：80L（ maximum ）

• Cleaning method ： Spray rotary cleaning and rinsing

• Dry way ： Heated air knife dry

• Recommended cleaning time ：5-20 mines

• Recommended rinse time ：2-3 mines

• Recommended drying time ：5-20 mines

• Cleaning filter ： Using 3-level filtration

• Class 1 filter ：2mm（ Filter impurities ）

• Class 2,3 filters ：100um/20um（ Filter flux, rosin and so on ）

• Blower ：3.7KW加Heated to 80°

• Electric pump ：2.2KW/1.1KW

• Diaphragm pump ： 1 inch diaphragm pump (pumping, drainage)

• Air supply ：0.5Mpa~ 0.7Mpa,600-800L/min

• power supply ：AC380V,3Phase,22KW

• weight ：about 500KG

• dimension ：1380(L) ×2100mm(W) ×1400mm(H)

Fixture Tool Auto Cleaning Machine,CW-5200 Advantages:

1. Touch screen display, one-button operation, one person cleaning, saving labor

2. Water-based cleaning fluid, environmental protection

3. The cleaning solution is recycled to save the solution

4. Batch cleaning ,cleaning fast and efficient

5. Equipped with a wind knife, can be completely dry

6. Up and down, around the full range of cleaning, cleaning thoroughly, high cleanliness

7. Spray cleaning, governance with intact
